Description
The Bolt On D-ring Anchor can be used in temporary or permanent applications.
Design allows for free movement of D-ring after installation. Ideal for use as a single point anchor or as part of a horizontal lifeline system.
Features:
- D-ring moves freely after installation
- Can be bolted or welded on
| Materials: | YCM plated steel D-ring and plate |
| Weight: | 1.2 lbs. (.5 kg) |
| Dimensions: | 1/4” x 2” x 4-1/2” |
| Minimum Breaking Strength: | 5,000 lbs. |
| ANSI Weight Capacity: | 130-310 lbs. (59-141 kg) |
| OSHA Weight Capacity: | Up to 420 lbs. (191 kg) |
| OSHA Standards: | 1926.502, 1910.140, 1910.66 |
